Harkwood 2-port Powerbox double USB-C.
Features a new fully configurable output per port of up to 45W (output voltage also configurable). EASA approved for motor-powered aircraft and any ELA2 aircraft under CS-STAN issue 4 section CS-SC038b or CS-SC102b. Form 123 is required. Compact charger for cell phone, PDA, etc.

Benefits:
- No interference with the aircraft radio.
- Compact dimensions.
- Quick and easy installation.
- Intelligent charging control (DCP).
- Thermal overload shutdown.
- USB charging voltage regulation is maintained within the defined standards, which prevents damage to devices under charge.
- Detection and isolation of any short circuit/fault, with auto recovery once the fault is removed (i.e. damaged cable/faulty device).
- Universal device support, without the need to resort to cheater cables.
- Software controlled device recognition means new devices/charging requirements can be accommodated via custom charging profiles.
- Status light indication of what is happing on each port.

Comes with power cables to connect to a 12-32V DC source, which can also be easily disconnected from the Powerbox via a simple connector. On the rear of the charger is also a USB-C connection (for configuration of the input and output power). To support devices that do not confirm to the standards, custom profiles can be uploaded via the management software.
Each port may have a different profile assigned.
Access to this port is via a Windows based Charger Manager application, which may be downloaded from the website.
This gives real time data on port status and current draw, plus management of portcustom profiles.


Input: 12-32V DC
Max input power: 8.25A @12VDC, 4.13A @24VDC Output 1: 5V-20V (max 45W), fully configurable via the charger manager application.
Output 2: 5V-20V (max 45W), fully configurable via the charger manager application.

Dimension:
L: 44mm
W: 60mm
H: 23mm

Weight: 90g
