Laminar Aerotec electric bugwiper system for double seater.
Suitable for many common aircraft types.
Fitted in a compact aluminum housing, both boxes have a removable cable drum with provision for optional wingspan adjustment.

Key features:
- Short cleaning time of approx. 15 seconds per wing, even at higher speeds.
- Three safety features: slack rope switch, slip clutch and automatic shutdown on overload.
- Simultaneous cleaning with both bug wipers possible.
- Various mounting plates for easy and flexible installation.


The set contains:
2x Elektric winches
2x Mounting plate No.1
2x Double switch for instrument panel
1x Installation kit (electric cabling, bowdencable, installation materials, etc.)
1x Installation and operating manual.

Excluding bugwipers.


Specifications:
Input voltage: 10 – 14,5V DC
Power consumption standby: 0A
Current consumption in operation: unwind 2.2A, rewind 5.5A
Current consumption max.: 8.5A
Fuse electric winch: 10A
Fuse battery minimum: 15A
Weight of system excl. bugwipers: 1.6kg
Dimension:
L= 152mm
W= 57mm
H=72mm



Please insert your plane type in the comments.
